Doosan Diesel Generator

As an integrated diesel engine manufacturer, Doosan Engine is specialized in diesel engines for large vessels, as well as the construction of internal combustion power plants that use diesel engines. Doosan Engine has the second largest global market share with an annual production capacity of 9 million bhp. With 20 years of experience, Doosan Engine recorded an annual order backlog of more than $ 1 billion in the last three consecutive years.

Type	Output Power		Cuurrent (A)	Engine model	Cylinder	Bore*Stroke (mm)	FuelCon. (L)	Dis. g/kw.h	Dimension(mm ) L*W*H	Weight(kg)	Detail
	KW	KVA
JHD-50GF	50	62.5	90	DB58	6	102*118	5.785	215	2000*730*1150	900	Click
JHD-64GF	64	80	115.2	D1146	6	111*139	8.071	222	2200*800*1500	1100	Click
JHD-75GF	75	93.7	135	D1146	6	111*139	8.071	222	2200*800*1500	1100	Click
JHD-100GF	100	125	180	D1146T	6	111*139	8.071	200	2300*800*1500	1500	Click
JHD-120GF	120	150	216	DP086TA	6	111*139	8.1	201	2300*800*1500	1600	Click
JHD-132GF	132	165	237.6	DP086TA	6	111*139	8.1	202	2300*800*1500	1600	Click
JHD-150GF	150	136	270	P086TI-1	6	111*139	8.071	207	2550*1000*1500	1750	Click
JHD-180GF	180	225	324	P086TI	6	111*139	8.071	202	2600*1000*1500	1800	Click
JHD-200GF	200	250	360	DP086LA	6	111*139	8.1	203	2700*1000*1500	1800	Click
JHD-220GF	220	275	396	P126TI	6	123*155	11.051	205	2900*1050*1650	2400	Click
JHD-240GF	240	300	432	P126TI	6	123*155	11.051	205	2900*1050*1650	2400	Click
JHD-260GF	260	325	468	P126TI-II	6	123*155	11.051	202	3000*1050*1650	2600	Click
JHD-300GF	300	375	540	P158LE-1	8	128*142	14.618	232	3100*1400*1850	2700	Click
JHD-320GF	320	400	576	P158LE-1	8	128*142	14.618	232	3100*1400*1850	2700	Click
JHD-350GF	350	437.5	630	P158LE	8	128*142	14.618	209	3100*1400*1850	2800	Click
JHD-400GF	400	500	720	P158LE-S	8	128*142	14.618	210	3120*1400*1850	3000	Click
JHD-440GF	440	550	792	P180LE	10	128*142	18.273	205	3300*1400*1850	3200	Click
JHD-500GF	500	625	900	P222LE-1	12	128*142	21.927	200	3400*1400*1850	3500	Click
JHD-550GF	550	687.5	990	P222LE-S	12	128*142	21.927	207	3400*1400*1850	3700	Click
JHD-600GF	600	750	1080	P222LE-II	12	128*142	21.927	210	3500*1400*1850	4000	Click
JHD-650GF	650	812.5	1170	P222FE-II	12	128*142	25.42	207	3600*1400*1850	4500	Click

1.Above technical parameters speed is 500RPM, frequency 50HZ, rated voltage 400 / 230V, power factor 0.8, and 3-phase 4-wire. 60HZ diesel generators can be made according to the specific needs of customers.

2.Alternator is based on customer needs, you can choose from Wuxi Stamford, Shanghai Hengsheng(recommend), Shanghai marathon and other famous brands.

3 The parameter list above are for reference only, subject to change without notice.
