What are the rules for transformer reactive power consumption?

The transformer consumes a certain amount of reactive power during operation, which has a certain impact on its operating efficiency and stability. Understanding the law of transformer reactive power consumption is of great significance for optimizing the operation of the power system and improving energy efficiency. This article will discuss the law of transformer reactive power consumption in detail and propose corresponding optimization measures.

1. Basic law of transformer reactive power consumption

Proportional to load size: The reactive power consumption of the transformer is closely related to its load size. When the load increases, the transformer needs to provide more reactive power to maintain normal operation, so the reactive power consumption will also increase accordingly. Conversely, when the load decreases, the reactive power consumption will also decrease accordingly.

Inversely proportional to the voltage level: There is a certain relationship between the reactive power consumption of the transformer and its voltage level. Generally speaking, the higher the voltage level, the smaller the reactive power consumption of the transformer. This is because the current is relatively small at high voltage levels, thereby reducing the loss of reactive power.

Related to the core material: The core material of the transformer also has a certain impact on its reactive power consumption. The use of high-quality core materials can reduce hysteresis loss and eddy current loss, thereby reducing reactive power consumption. At the same time, a reasonable core structure design can further reduce reactive power consumption.

Related to the operating state: The operating state of the transformer also has a significant impact on its reactive power consumption. When the transformer is in no-load or light-load operation, its reactive power consumption is relatively small; when the transformer is in heavy-load or overload operation, its reactive power consumption will increase significantly. In addition, the temperature rise, noise and other indicators of the transformer will also have a certain impact on its reactive power consumption.
